    3.2mm Building Material C Purlin Machine Steel Roll Forming Machine ISO9001

    Ask Lasest Price
    Brand Name : THRONCH
    Certification : CE.ISO
    Delivery Time : Depends on the items and the quantity of your order.
    Payment Terms : TT / LC
    Price : USD 10000-100000 PER SET
    Supply Ability : 20 SETS/ MONTH
    • Product Details
    • Company Profile

    3.2mm Building Material C Purlin Machine Steel Roll Forming Machine ISO9001

    High Standard Purlin C & Z Channel Steel Roll Forming Machine for Building Material
    PRODUCT DESCRIPTION
    Features & Purposes:
    C-type steel machine strengthens its firmness with an arch type, stabilizes its operation
    with gearbox drive, and improves product quality by adopting molding shearing to avoid
    port deformations.Products are widely applied in purline set-up of steel-structure houses.
    Specification:
    item
    value
    Type
    Steel Frame & Purlin Machine
    Applicable Industries
    Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Construction works
    Showroom Location
    None
    Video outgoing-inspection
    Provided
    Machinery Test Report
    Provided
    Warranty of core components
    2 years
    Core Components
    PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump
    Condition
    New
    Production Capacity
    30m/min
    Voltage
    480V 60Hz 3P
    Power
    22Kw
    Dimension(L*W*H)
    10200x1350x1750mm
    Weight
    10000kg
    Warranty
    2 years
    Key Selling Points
    Automatic
    Product name
    Automatic C&Z purlin roll forming machine
    After-sales Service Provided
    Online Support
    Usage
    Steel Construction
    Raw material
    PPGI,PPGL G550
    Material of rollers
    G-Cr15 roller of purlin machine
    Roller stations
    18 rows
    Diameter of shafts
    75mm solid
    Control system
    PLC
    Transmission way
    By 1.5 inch chain
    Certification
    CE ISO

    Working flow:



    Technical parameters:


    Voltage380V/50HZ/3PH
    Motor Power15KW
    Forming Steps13steps+3steps for reshaping
    Forming Speed10-15m/min
    Effect Width100-300mm
    Thickness1.5-3.0mm
    Tolerance±1mm
    Roller MaterialGcr15, quench treatment hardness 55-58
    Material of principal axisHigh grade 45# forged steel
    Shaft material45# steel high-frequencies quench
    Cutting systemHydraulic cutting
    Material for BladeCr12 mold steel with quenched treatment 60-62°C
    Raw materialGalvanized Steel
    Painted ColorCustomers requirement

    Product display:


    Packing shipping:

    FAQ:

    Q1. What are the main key points for selecting right machines?

    A1: Whole structure,Roller Shaft,Roller Material,Motor&Pump,and Control system. As the new buyer, please kindly know that price not the final point. Good quality is for long-term business cooperation.
    Q2. Can you provide OEM service for roll forming machine?
    A2: Yes, most of cold roll forming machine need to be customized as detailed request, because raw material , size , production usage, machine speed, then machine specification will be some different.
    Q3. What’s your standard trade terms ?
    A3: We can provide the technical offer with FOB,CFR,CIF,Door to Door and so on. Please kindly tell the detailed port name for competitive ocean freight.
    Q4. How about the quality control?
    A4: Our company adopts 6S system to control every part with passed ISO9001:2000, CE,TUV/BV(.) Certificate.
    Q5. How about the after-sale service?
    A5: We provide 18 months free warranty and free technical support for the whole life of any machine. During warranty period, if parts still broken, we can send the new ones freely.
